Ives Full Mortise

Ives Architectural Hinges Specifications

Guidelines for Number of Hinges per Door

- Doors Under 7'6" – 3 Hinges
- Doors Over 7'6"– 4 Hinges

Selections of the Proper Weight and Bearing Type:

• Standard Weight - Plain Bearing
• Standard Weight - Ball Bearing, Concealed Bearing
• Heavy Weight - Ball Bearing, Concealed Bearing

Considerations to Determine Weight and Bearing Type:
Weight of Door, Frequency of Use, Frame, and Door Hardware.

Always use ball bearing or concealed bearing hinges for doors with door closers and in all fire rated openings. Heavy weight doors and high frequency doors should use heavy weight ball bearing or concealed bearing hinges.

Guidelines for Hinge Material

• Interior door or non-corrosive area use: Plated or Painted Steel
• Interior labeled door use: Plated or Painted Steel, Stainless Steel
• Interior door in corrosive area use: Stainless Steel , Brass, Bronze
• Exterior doors use: Stainless Steel, Brass, Bronze

NOTE: Standard pin material are:  Brass Hinge – Steel Pin, Stainless Steel Hinge – Stainless Steel Pin, Steel Hinge – Steel Pin.

Considerations to Determine Hinge Size:
Door Width, Door Thickness, Weight, Clearance.

Architectural Hinges

3PB1 - 3 Knuckle, Plain Bearing Full Mortise Hinge

• For standard weight doors
• Low frequency usage
• Packed with wood and metal screws
• Not for use with a door closer

3CB1 - 3 Knuckle, Concealed Bearing Full Mortise Hinge

• For standard weight doors
• Medium frequency usage
• Packed with wood and metal screws

3CB1HW - 3 Knuckle, Concealed Bearing Full Mortise Hinge

• For heavy weight doors
• High frequency usage
• Packed with wood and metal screws

3SP1 - 3 Knuckle Spring Full Mortise Hinge

• For automatic closing of doors
• Packed with wood and metal screws

5PB1 - 5 Knuckle, Plain Bearing Full Mortise Hinge

• For standard weight doors
• Low frequency usage
• Packed with wood and metal screws

* Not for use with a door closer.

5BB1 - 5 Knuckle, Ball Bearing Full Mortise Hinge

• For standard weight doors
• Medium frequency usage
• 2 ball bearing
• Packed with wood and metal screws

5BB1HW - 5 Knuckle, Ball Bearing, Heavy Weight Full Mortise Hinge

• For heavy weight doors
• High frequency usage
• 4 ball bearing
• Packed with wood and metal screws

5BB1WT - 5 Knuckle, Ball Bearing, Wide Throw Full Mortise Hinge

• For medium weight doors
• Medium frequency usage
• 2 ball bearing
• Packed with wood and metal screws

5BB4 - 5 Knuckle, Ball Bearing, Half Surface Hinge

• For standard weight doors
• Medium frequency usage
• 2 ball bearing
• Packed with through bolts, grommets and sheet metal screws

5BB4HW - 5 Knuckle, Ball Bearing, Half Surface Heavy Weight Hinge

• For heavy weight doors
• High frequency usage
• 4 ball bearing
• Packed with through bolts, grommets and sheet metal screws

5BB1SC - 5 Knuckle, Ball Bearing, Swing Clear Full Mortise Hinge

• For standard weight doors
• Square edge standard
• Medium frequency usage
• 2 ball bearing
• Packed with flat head wood and metal screws

* Designed to completely clear the opening when door is opened 92 degrees.

5BB1SCHW - 5 Knuckle, Ball Bearing, Swing Clear Heavy Weight Full Mortise Hinge

• For heavy weight doors
• Beveled edge standard
• High frequency usage
• 2 ball bearing
• Packed with flat head wood and metal screws

* Designed to completely clear the opening when door is opened 92 degrees.

Electrified Hinge

Available Options:

• Through Wire - TW4 (4 wires) & TW8 (8 wires)
• Monitor – MON
• Through Wire with Monitor – TW4M & TW8M
• Available in 3 and 5 Knuckle
• One hinge per box, packed with wood and machine screws
• Hinge is NRP as a standard
• High quality brass ferrules and plastic tubing protect the wires

Through-Wire Features:

• Through-wire hinges cycle tested to ensure durability
• Through-Wire is rated for 50 volts AC/DC at 3.5 amp continuous and 16 amp pulse, maximum pulse 400 mili second
• Monitor rated 30VDC at .5 amp
• Ives warranty applies, 12 months from date of shipment

Continuous Hinges

Ives Continuous Hinges are designed to last the life of the building. The unique design distributes the weight of the door along the entire length of the frame, reducing the high amount of stress normally associated at top of door and frame on butt hinge applications. Not only does this reduce hinge failure, it also keeps your door in constant alignment, eliminating the chance of door sag. These characteristics make continuous hinges suitable for high use/high traffic doors.

The design of a continuous hinge eliminates the gap between the door and the frame. The absence of gap also helps prevents finger from being pinched, making it a safer device than traditional hinges. These these benefits result in higher efficiency and less maintenance, maximizing the value of your opening investment.

Continuous hinges are available in two styles: aluminum geared, or pin and barrel, in steel or stainless steel finish.

Aluminum Geared

Geared continuous hinges utilize a single gear section for the leaf and a separate gear section for the frame side of the door. The two are held in place together by a full length cover channel and rotate on a series of bearings.
