Residential & Multi-family > Hardware > Multi-Family Electronic Deadbolts

Multi-Family Electronic Deadbolts

Introducing the next generation of electronic access for the world of multi-family: Schlage Control™ Smart Locks. More than a solution for streamlining operations and boosting a property’s appeal, it’s a new era of answers for every door you manage.

Schlage Control Smart Deadbolts and Schlage Control Smart Interconnected Locks eliminate dealing with traditional keys, while giving residents convenient smart card and phone credentials. Open architecture design delivers the ability to manage both residence and common area doors on the same system.

Schlage Control comes standard with ENGAGE™ technology, which provides connectivity and lock management for facilities staff through the ENGAGE app. This technology also allows residents to gain access using sophisticated smart technology. From a smart phone, tablet or computer, you can quickly add users, view a history of access, get data, receive alerts and more.

Designs
Specifications
Downloads

Schlage Finishes

All
×
505/605 Bright Brass
505/605 Bright Brass
608 Satin Brass
609 Antique Brass
618 Polished Nickel
619 Satin Nickel
620 Antique Pewter
621 Distressed NIckel
622 Matte Black
625 Bright Chrome
626 Satin Chrome
630 Satin Stainless Steel
716 Aged Bronze

Schlage Smart Deadbolt with Addison Trim

BE467 ADD

Schlage Smart Deadbolt with Addison Trim

Modern credentials – use a smart credential or phone as a key
Wireless freedom – control and program locks by phone
No-tour functionality – ability to alter access to a lock without having to visit it

Schlage Finishes Click swatch to change preview

619 Satin Nickel

625 Bright Chrome

626 Satin Chrome

716 Aged Bronze

Schlage Smart Deadbolt with Greenwich Trim

BE467 GRW

Schlage Smart Deadbolt with Greenwich Trim

Modern credentials – use a smart credential or phone as a key
Wireless freedom – control and program locks by phone
No-tour functionality – ability to alter access to a lock without having to visit it

Schlage Finishes Click swatch to change preview

619 Satin Nickel

625 Bright Chrome

626 Satin Chrome

716 Aged Bronze

Schlage Control Smart Deadbolt Features

Increases efficiency of property operations
Eliminates the cost and hassle of managing keys
Modern credentials – use a smart credential or phone as key
Wireless freedom – control and program locks by phone
No-tour functionality – ability to alter access to a lock without having to visit it
Improves security and safety, reduces liability
Keyless, no cylinder design - 100% pick and bump proof
Designed for accessibility
Upgrades property visual appeal
Increases property value
Supports both online and offline applications
Up to 500 users per lock
Audit trail reports up to 1,000 events
Fits standard door prep
Available to order lock less lever (chassis)
2-year battery life (Off-line mode)
Full suiting with Schlage decorative mechanical locks
ADA compliant design

Specifications

Latch: 1" x 2-1/4" square and round corner faceplate (round corner standard, square corner included in package), 1" edge bore required
Strikes: 1-1/8” x 2-3/4”, round corner, no box, latch strike
Backset: Adjustable backset, fits 2-3/8” to 2-3/4” backsets
Door Range: 1-3/8” to 1-3/4” (thick door kit available – up to 2-1/4”)
Latch: 1" x 2-1/4" square and round corner faceplate (round corner standard, square corner included in package), 1" edge bore required
Battery: 4-AA batteries (included), 9V Battery Backup (If loss of battery power occurs, a 9V battery can be used to jump start the lock and provide access with an assigned credential.)
Construction: All-metal chassis and escutcheons
Bore: 2-1/8”
Credential: Supports aptiQ MIFARE classic, aptiQ DESFire EV1 and aptiQmobile credentials
Stile Width: Minimum 4-1/2” stile for 2-3/8” backset, minimum 5” stile for 2-3/4”
Return to Door: Saturn (SAT) and Neptune (NEP) are return to door code compliant
Center to Center: Fits 4” or 5-1/2” center to center door preps – orderable options (please specify when ordering)
Certifications: 90-minute UL Listed, Grade 2 ANSI/BHMA certified
Full suiting with Schlage decorative mechanical locks
ADA compliant design

Easy Installation

No wiring or modifications of door frames required
Ideal for both new construction and retrofits
An electronic access solution that doesn't require an electrician to install
Only 2 tools required; a tape measure and a Phillips screwdriver

ENGAGE Technology

Schlage Control Smart Locks come standard with ENGAGE™ technology, which provides connectivity and lock management for facilities staff through the ENGAGE app. This technology also allows residents to gain access using sophisticated, smart credentials. By simply holding a smart credential up to the lock, they can open it, step through the door and be at home.

ENGAGE is a connectivity platform that simplifies the ability to connect people and openings to deliver cost effective intelligence and efficiency to any facility.
Conveniently retrofits into standard ND door prep without drilling additional holes
Installs in about 15 minutes with just a Phillips screwdriver
Compatible with proximity as well as aptiQ™ and aptiQmobile™ smart credentials
ENGAGE cloud-based web and mobile apps make it simple to configure lock settings, add users, and view audits and alerts from anywhere
