Residential & Multi-family > Hardware > Electronic Deadbolts

Schlage Keypad Locks & Deadbolts

Experience keyless freedom with Schlage keypad locks and deadbolts, revolutionary products that bring security to a new level—the convenience of keyless entry with the superior quality you expect from Schlage.

Innovative Turn Lock feature allows you to lock and leave without a key and provides the convenience of keyless access, customizable to fit your security needs. Ideal for front doors, garage doors, side and back doors.

For additional product styles and options, visit www.schlage.com.

Designs
Specifications
Downloads

Keypad Deadbolt - Camelot Satin Nickel

BE365V CAM 619

Keypad Deadbolt - Camelot Satin Nickel

Keypad Deadbolt with Camelot Escutcheon in Satin Nickel

Silicone rubber, wear-resistant buttons with LED backlight
No programming required; preset with two user codes so it is ready right out of the box.
19-user code capacity. Easily programmed right at the keypad.

Keypad Deadbolt - Camelot Matte Black

BE365V CAM 622

Keypad Deadbolt - Camelot Matte Black

Keypad Deadbolt with Camelot Escutcheon in Matte Black

Silicone rubber, wear-resistant buttons with LED backlight
No programming required; preset with two user codes so it is ready right out of the box.
19-user code capacity. Easily programmed right at the keypad.

Keypad Deadbolt - Camelot Aged Bronze

BE365V CAM 716

Keypad Deadbolt - Camelot Aged Bronze

Keypad Deadbolt with Camelot Escutcheon in Aged Bronze

Silicone rubber, wear-resistant buttons with LED backlight
No programming required; preset with two user codes so it is ready right out of the box.
19-user code capacity. Easily programmed right at the keypad.

Keypad Deadbolt - Plymouth Satin Nickel

BE365V PLY 619

Keypad Deadbolt - Plymouth Satin Nickel

Keypad Deadbolt with Plymouth Escutcheon in Satin Nickel

Silicone rubber, wear-resistant buttons with LED backlight
No programming required; preset with two user codes so it is ready right out of the box.
19-user code capacity. Easily programmed right at the keypad.

Keypad Deadbolt - Plymouth Satin Chrome

BE365V PLY 626

Keypad Deadbolt - Plymouth Satin Chrome

Keypad Deadbolt with Plymouth Escutcheon in Satin Chrome

Silicone rubber, wear-resistant buttons with LED backlight
No programming required; preset with two user codes so it is ready right out of the box.
19-user code capacity. Easily programmed right at the keypad.

Keypad Lock - Camelot/Accent Satin Nickel

FE595V CAM/ACC 619

Keypad Lock - Camelot/Accent Satin Nickel

Keypad Lock with Camelot Escutcheon and Accent Lever in Satin Nickel

Silicone rubber, wear-resistant buttons with LED backlight
No programming required; preset with two user codes so it is ready right out of the box.
19-user code capacity. Easily programmed right at the keypad.

Keypad Lock - Camelot/Accent Aged Bronze

F595V CAM/ACC 716

Keypad Lock - Camelot/Accent Aged Bronze

Keypad Lock with Camelot Escutcheon and Accent Lever in Aged Bronze

Silicone rubber, wear-resistant buttons with LED backlight
No programming required; preset with two user codes so it is ready right out of the box.
19-user code capacity. Easily programmed right at the keypad.

Keypad Lock - Plymouth/Elan Satin Chrome

F595V PLY/ELA 626

Keypad Lock - Plymouth/Elan Satin Chrome

Keypad Lock with Plymouth Escutcheon and Elan Lever in Satin Chrome

Silicone rubber, wear-resistant buttons with LED backlight
No programming required; preset with two user codes so it is ready right out of the box.
19-user code capacity. Easily programmed right at the keypad.

Keypad Combo - Camelot/Accent Satin Nickel

FBE365V CAM/ACC 619

Keypad Combo - Camelot/Accent Satin Nickel

Keypad Deadbolt/Lever Combo with Camelot Escutcheon and Accent Lever in Satin Nickel

Silicone rubber, wear-resistant buttons with LED backlight
No programming required; preset with two user codes so it is ready right out of the box.
19-user code capacity. Easily programmed right at the keypad.

Programmable Keypad Lock and Deadbolt Functions

Convenient keyless access; no keys to hide, lose or forget
Fits standard door prep; no additional mounting holes required
Pre-set with random 6-digit programming code and two random 4-digit user codes; no programming required
19-user code capacity; 10,000 user code combinations
Easily programmed right at the keypad; no need to remove inside escutcheon
Blue LEDs illuminate the keypad on demand for evening use
Silicone rubber, wear-resistant buttons
Locks can be re-keyed to match existing locks
9-volt alkaline battery included, low battery warning and average 3-year life
Easy access to replace battery
BE365 and FE285 available UL Listed (Box Pack Only)

Standard Features / Configurations

Applications: Residential single- and multi-family doors
Certifications: Grade 2 ANSI/BHMA certified
Keying: 5-pin tumbler C keyway with two nickel silver keys
Door range: 1-3/8” to 1-3/4” (35mm-44mm) standard; thick door kit available on BE365
Backset: Universal latches and deadbolts fit 2-3/8” (60mm) or 2-3/4” (70mm) backset

Professional Grade Security and Quality

Grade 2 ANSI/BHMA certified
Patented commercial grade clutching motor drive; tested to one million cycles
Vandal resistant clutching lever and knob design; free spinning deadbolt turn
Code control; 6-digit programming code required to add and delete user codes
Warning code sounds after four incorrect codes entered; keypad disabled for 30 seconds
Mechanical key override; patent pending

Available Finishes

Latches & Strikes

Limited lifetime mechanical and finish warranty
Limited three year electronics warranty
Keypad lock latch: 1” x 2-1/4” (25mm x 57mm) latch with radius corner faceplate, 7/8” (22mm) housing diameter, 1/2” (13mm) throw spring latch with square corner and circular drive-in faceplates
Keypad deadbolt latch: 1” x 2-1/4” (25mm x 57mm) radius corner faceplate, 1” (25mm) housing diameter, requires 1” (25mm) edge bore, 1” (25mm) throw with square corner and circular drive-in faceplates
Latch strikes: 1-5/8” x 2-1/4” (41mm x 57mm), square and radius corner, full lip
Deadbolt strike: 2-3/4” (70mm), round corner, latch strike, metal strike reinforcer
Cylinder: 5-pin solid brass, keyed 5-pin, C keyway, keyed different (KD)
